Double Layer Paper Making Forming Fabric with Eight over Sixteen Shed Weave and Extra CD Support Yarns for High Fiber Retention and Drainage

Nombre De La Marca: ATMC
MOQ: 1 pieza
Precio: inquiry
Detalles Del Embalaje: Casilla estándar de madera de recubrimiento para la exportación
Condiciones De Pago: LC, D/A, D/P, T/T
Información detallada
Estructura:
/
Descripción del modelo:
/
Las redes de malla × número (l/cm):
/
Diámetro de curvatura (mm):
/
Diámetro de la trama (mm):
/
Warp / Weft Material:
/
Permeabilidad al aire:
/
Calibre (mm):
/
Fuerza de la rotura:
/
Peso (GSM):
/
Indice de apoyo a la fibra (FSI):
/
Indice de drenaje (DI):
/
Área abierta:
/
Color de la tela:
/
Resaltar:

Double layer paper forming fabric

,

Eight over sixteen shed weave fabric

,

High fiber retention drainage fabric

Descripción del producto
Double Layer Paper Making Forming Fabric with Eight over Sixteen Shed Weave and Extra CD Support Yarns for High Fiber Retention and Drainage
The PRINT DAL67816SM is a double layer forming fabric engineered with a fine eight shed paper side weave over a sixteen shed wear side construction. The paper side features extra cross direction support yarns that deliver high fiber retention, while the robust wear side incorporates a pronounced CD crimp with large diameter yarns for extended life potential. This unique combination achieves both high fiber support and very high drainage capacity within a single fabric design. The large diameter CD crimp on the machine side effectively protects MD warp yarns from abrasion and increases wear yarn mass. The robust construction withstands high MD loads and resists CD ridging, making this fabric suitable for printing and writing paper, light weight kraft, and board grades.
Key Features
  • Eight over sixteen shed double layer weave construction
  • Fine mesh eight shed paper side with extra CD support yarns
  • Sixteen shed wear side weave for good service life
  • High fiber support for excellent retention performance


Product Parameters
Product Name Forming Fabric PRINT DAL67816SM
Material Polyester monofilament
Function Paper Machine
Application Printing & Writing Paper, Newsprint Paper, etc.
Technical 1/1.5/2/2.5/3 layers forming fabric
Width Customized
Weigh Customized
Fabric Color Customized
Product Images
Double Layer Paper Making Forming Fabric with Eight over Sixteen Shed Weave and Extra CD Support Yarns for High Fiber Retention and Drainage 0
Top Side View
Forming Fabric KRAFT SL2105L - Bottom Side View
Bottom Side View
Application

Printing & Writing Paper, Newsprint Paper, etc..

Double Layer Paper Making Forming Fabric with Eight over Sixteen Shed Weave and Extra CD Support Yarns for High Fiber Retention and Drainage 2
